37GB555 (JGB37-555) is a high-performance micro DC geared motor with a 37mm metal gearbox and 555 DC motor core. It features high torque, low speed, stable operation and long service life, widely used in smart home, automation equipment, robots and DIY projects.
Key Features
- High torque output at low speed with metal gear structure
- Wide voltage range: DC 6V, 12V, 24V optional
- Support forward and reverse rotation and PWM speed adjustment
- Pure copper coil, low noise, high efficiency and strong durability
- Standard D-shaft output for easy installation and connection
Specifications
- Model: 37GB555 / JGB37-555
- Gearbox Diameter: 37mm
- Voltage: DC 6V / 12V / 24V
- Speed: 5rpm – 1500rpm (depends on reduction ratio)
- Torque: 0.5kgf·cm – 40kgf·cm
- Shaft Type: D-type shaft
- Gear Material: Metal
Applications
- Smart robot, RC car, robotic arm
- Automatic curtain, door lock, window opener
- Vending machine, electronic lock, financial equipment
- Smart home appliances and small automation devices
- DIY projects, model making, intelligent instruments
Difference from 37GB520
37GB555: The motor body is RS-555, which has higher power, stronger torque, and higher load capacity
37GB520: The motor body is RS-520, with slightly smaller volume/power/torque, suitable for light load scenarios
Motor Characteristics
