Description

SPECIFICATIONS

Automation Industrial Solid State Amplifier module CM-SSR

Range : 430-450Mhz

Output type: NPN

Output points: 6I/6O

Motor Type: AC Motor

Model Number: CM-SSR

Installation : Standard rail , NS35/7.5

Input voltage: 88-264VAC or 125-373VDC

Input type: NPN

Dimension : 89.5*79*32.5mm

Connection mode: 5.08 pluggable terminal

Brand Name: Coolmay

Automation Industrial Solid State Amplifier module CM-SSR

The Coolmay CM-SSR amplifier board converts the PLC’s low-power output signal into optocoupler and converts it into a high-power output control signal, and then drives the high-power load such as the motor and solenoid valve to protect the PLC. This product is compact in structure, stable in performance, easy to use, non-contact switch, response time as low as milliseconds, no switching times, long service life, can directly replace traditional relays, reducing maintenance time and reducing costs.

Features:

1, with opto-isolator, isolation and protection of PLC output contacts2, compact structure, easy to install; help reduce the size of the control box, reduce costs3, input with indicator light, is conducive to debugging4, with standard rail card installation, easy to install5, input and output side arrangement, with pluggable terminals, easy to route and install maintenance6, small size, beautiful appearance7, stable performance, durable, strong anti-interference ability8, the output current is largeParameters

Artical	Amplification module
	CM-MOS	CM-SSR	CM-REY
	Transistor amplification module	Solid state amplification module	Intermediate  amplifier module
Installation	Standard guide rail’s installation,can be installed on NS357.5or NS32 guide slot
Dimension	89.5*79*32.5mm
Connection mode	5.08 pluggable terminal
Input voltage	88-264VAC or 125-373VDC( withstand 300VAC surge input for 5s without damage)
Input type	NPN
Working voltage	DC12~30V	AC100~250V	DC/AC0~250V
Output current	5A	5A	15A
Max. Output current	10A	10A	16A
Output method	MOS	Zero-crossing trigger	Relay tip
Output points	6I/6O
Output type	NPN
Protection method	optoelectronic isolation,FWD protction	optoelectronic isolation,RC absorption circuit	Relay-isolated, 400V piezoresistor
Detail info refer to	< Coolmay Amplifier User Manual>
