Description

SPECIFICATIONS

Brand Name: Anmiy

Certification: NONE

Origin: Mainland China

Commutation: Brushless

Type: Micro Motor

Protect Feature: Drip-proof

Construction: Permanent Magnet

Usage: car

Model Number: BL2418-S0222R

Model: BL2418-S0222R
Gear Box Name: –
Gear Box Type: –
Motor Body Name: BL2418
Motor Body Type: DC Brushless Motor (BLDC)
Shaft Number: Single
Shaft Size: 2mm(diameter) * 22mm(length)
Shaft Shape: Round
Rated Voltage: DC 24V (can be reduced to 12V, etc.)
Motor Weight: 26g (approx.)
Motor Use Temperature: 0℃ – 70℃
Motor Storage:
– Temperature: 0℃ – 40℃
– Humidity: 15% -90% RH
The BL2418 is DC Brushless Motor with high reliability, no electric spark, low noise, adjustable speed, forward and reverse rotation, etc.
The BL2418 motor’s rated voltage is DC 24V, it can be reduced to 12V, etc. When the voltage is reduced, its speed, current and torque are reduced accordingly in proportion.
The Speed (RPM) in the purchase option is DC24V.
When the voltage is reduced to 12V, the speed is about 1/2 of those of 24V.
The No-load Speed at rated voltage DC 24V (Speeds in purchase options) is:
9000 RPM
The No-load speed at DC 12V is (Speeds in purchase options divided by 2):
4500 RPM
For more voltages and speeds, please contact us.
Package included:
– 1 x Motor

Notes:
1. VCC and GND must not be misconnected.
2. CW/CCW, PWM, BRAKE could not be connected to VCC.
3. Prohibit CW/CCW signal while the motor is running. When you need to switch the direction, please stop the motor first, then set the correct CW/CCW according to the expected motor rotation direction, and then start the motor.
4. For gear motors, the FG output pulse must to be multiplied by the reduction ratio of the gearbox.

Notes: Pin connect for DC brushless motor describes how the motor’s pins are connected when the motor is started, and how the speed and brakes are controlled.
