Description

SPECIFICATIONS

2pcs 555 High Speed DC Mini Motor Electric 12 V 24V 4000rpm 8000rpm PWM Motors DC12V High Torque Shaft Dia 3.175mm DIY Engine

Brand Name: HYSMOTOR

Certification: CCC

Certification: ROHS

Origin: Mainland China

Commutation: Brush

Type: Micro Motor

Protect Feature: Drip-proof

Construction: Permanent Magnet

Model Number: 555 High Speed Motor

555 motor, 3.175mm shaft diameter, need 12V voltage to drive! It is suitable for making all kinds of small manual productions.

Rated Voltage: 12VProduct speed: about 1200 rpmMotor diameter: 38mmStep height: 4.2mmStep diameter: 13mmMotor length]: 57mm (without shaft)Shaft diameter of shaft]: 3.17mmMotor shaft length: 10mmMounting hole distance: about 24.5mmInstallation aperture: M3 (fixed with 3mm screws)

550/545/555 motor base Mount (black L type),this product is made of aluminum alloy, which is better than iron motor base, light weight, high strength, blackened appearance, anti-rust and durable

Note: The motor base is not equipped with screws. If you need to fix the screws, please purchase M3 screws for use.Size: 40 * 43mm on the bottom, 47mm in heightThickness: 3mm thick aluminum alloyCenter aperture: about 12.8mmSide fixing hole distance: 25mmBottom fixing hole distance: 25mm, 30mm (transverse)Side fixed aperture: M3 holeUnderside fixed aperture: M3 hole
